Energy cases
Power to go
Certainly enough power when it counts: B&W energy.cases, the mobile power supply for professionals.
- Designed for demanding outdoor use: waterproof and temperature-resistant from -20 to +40°C.
- Individual requirements thought through in advance: we adapt connections, charging options and services to your needs.
- B&W energy.cases can be flexibly configured for direct current or alternating current.
- User-friendly controls for intuitive operation.
- Manufactured in Germany - development and assembly in Münsterland.
HOW MOBILE POWER SUPPLY WORKS TODAY
The B&W energy.case is your reliable companion for mobile power in the professional sector! Robust, temperature-resistant and waterproof, the energy.cases are designed for wind and weather and are also ideally suited for stationary operation. Operation is intuitive and uncomplicated.
Designed for permanent outdoor use. All components are vibration-protected.
LiFEPo4 battery system with intelligent battery management and comprehensive monitoring.
Thanks to the NFC chip, you can easily access the operating instructions for the energy case.
The energy.cases are developed and manufactured in Germany. The circuit boards are made in Germany.
Charging options: Mains adapter, car charging cable, solar cells.
The AC models have one 230V and two USB outputs as well as 2 charging inputs. Customizations are possible.
Different areas of application? The energy.cases can be configured for both AC and DC connections.
Customized configuration
Our energy.cases were developed as a modular system to allow for customized implementations.
Various models
All basic models are designed for adaptability.
Different connections and output voltages can be integrated and solutions for combining AC & DC outputs are available.
|
energy.case PROX 1500 AC 1000W |
energy.case PROX 1500 AC 300W |
energy.case PROX 1500 AC UPS (uninterruptible power supply) |
energy.case PROX 500 AC 300W |
energy.case PROX 1500 DC 1000W |
energy.case PROX 500 DC 1000W |
|
|
Tension
|
230V |
230V |
230V |
230V |
24V DC |
24V DC |
|
Connection & System AC
|
1 x 230V socket outlet, 1 x USB PD 65W, 1 x charging input |
1 x 230V socket outlet, 1 x USB PD 65W, 1 x charging input |
1 x 230V socket outlet, 1 x 230V IEC socket outlet |
1 x 230 V socket outlet, 1 x USB PD 65W, 1 x charging input |
2 x 24V 500W DC socket outlet, 1 x USB PD 65W, 1 x charging input |
2 x 24V 500W DC socket outlet, 1 x charging input |
|
Battery capacity
|
1500Wh |
1500Wh |
1500Wh |
500Wh |
1500Wh |
500Wh |
|
Continuous power
|
1000W |
300W |
1000W |
300W |
1000W |
1000W |
|
Remote control
|
inclusive |
optional |
N/A |
inclusive |
inclusive |
inclusive |
|
Control via CAN-BUS
|
possible |
possible |
possible |
possible |
possible |
possible |
|
Charging power
|
350W |
350W |
350W |
350W |
350W |
350W |
|
Charging options
|
230V power supply units (350W) |
230V power supply units (350W) |
230V power supply units (350W) |
230V power supply unit (350W) |
230V power supply units (350W) |
230V power supply unit (200W) |
|
Operating temperature
|
-20°C - +45°C |
-20°C - +45°C |
-20°C - +45°C |
-20°C - +45°C |
-20°C - +45°C |
-20°C - +45°C |
|
Dimensions
|
66 x 49 x 33.5 cm |
66 x 49 x 33.5 cm |
66 x 49 x 33.5 cm |
51 x 42 x 21.5 cm |
66 x 49 x 33.5 cm |
51 x 42 x 21.5 cm |
|
Case type
|
bw.case PP.709 | Type 6800 |
bw.case PP.709 | Type 6800 |
bw.case PP.709 | Type 6800 |
bw.case PP.326 | Type 6000 |
bw.case PP.709 | Type 6800 |
bw.case PP.326 | Type 6000 |
|
Weight
|
33.3 kg |
31.2 kg |
32.5 kg |
16.5 kg |
28.8 kg |
15.5 kg |
|
Keyboard
|
Internal, |
Internal, |
External |
Internal, |
Internal, |
Internal, |
|
Further information
|
|
|
|
|
|
|
Flyer
Contact person
If you would like to find out more about these products or request a quote, our staff will be happy to help.
Do you have any questions about our products?
FAQ
We have answered the most frequently asked questions here. If you have any further questions, please do not hesitate to contact us.
What is the energy case and what is it used for?
The energy.case from B&W is a mobile power supply solution for professional applications. It combines robustness, flexibility and reliability and is ideal for use in industry, trade, outdoor activities or crisis situations.
What distinguishes the B&W energy case from other mobile power solutions?
The energy case from B&W offers a unique combination of robustness, flexibility and adaptability. Compared to conventional solutions, it scores points with certified safety standards, an innovative design and versatile application options - from construction sites to outdoor adventures. We can also offer you our energy.cases in smaller quantities, individually adapted to your needs.
What does IP mean?
IP stands for "Ingress Protection" and describes the impermeability class of a device. This classification indicates how well a device is protected against the ingress of foreign bodies (e.g. dust) and water.
The IP class consists of two digits:
- First digit: Protection against foreign bodies and contact (e.g. dust).
- Values range from 0 (no protection) to 6 (dust-tight).
- Second digit: Protection against water.
- Values range from 0 (no protection) to 9 (protected against high-pressure water jets).
Is the energy case waterproof?
Yes, the energy.cases are waterproof to IP54 or IP65.
IP54: is suitable for use in dusty environments and is resistant to rain or splashing water. However, it is not completely waterproof and should not be immersed in water.
IP65: is completely dustproof and can withstand strong water jets, but is not suitable for permanent submersion.
What are the advantages of the B&W energy case?
The energy case is temperature-resistant, waterproof and maintenance-free. With its versatile connections and configuration options, it offers a flexible power supply that can be adapted to individual requirements. Perfect for demanding environments.
What is the NFC chip in my energy case for? Which app do I need to use the chip?
With the NFC chip, which is integrated in products such as battery.case, starlink.case and energy.case, consumers can quickly and easily access the operating instructions for the respective products by simply scanning the NFC chip.
This is how the NFC chip works:
- Android users: Require an NFC app and must activate NFC in the settings
- iPhone users (from iPhone 7): The NFC tag is read automatically, without an additional app
Benefits of this feature:
Convenience: Users can quickly access important information without having to search for printed instructions or documents.
Paperless: This feature promotes paperless access to operating instructions and saves resources.
Ease of use: Especially for technical products such as battery.case, starlink.case or energy.case, it is an efficient way to make it easier for consumers to access important information.
Can I connect several energy cases in series?
Yes, this is possible under certain circumstances. However, the direct series connection of several energy.cases is not intended due to technical and safety-related restrictions.
Indirect connection:
By using external devices such as distributors or suitable charging stations, several energy.cases can be used at the same time, supplying energy independently of each other.
Please contact this e-mail address for detailed information: info@b-w-international.com
For which sectors is the energy case suitable?
The energy case is used in a wide variety of areas, including construction, rescue services, outdoor adventures, events, defense and in the installation or maintenance of technology. It provides reliable service, particularly in crisis regions or for mobile applications.
How is the energy case charged?
The B&W energy case can be charged flexibly - via 230V mains adapters, 12V car connections, 24V truck sockets or even solar panels. This versatility makes it ideal for mobile and self-sufficient applications.
What are the technical specifications of the energy case?
Depending on the model, the B&W energy cases offer battery capacities from 500 to 3000 Wh and various connections, including USB, 230 V sockets and DC sockets. They are designed for temperatures from -20°C to +40°C and are certified to protection classes such as IP54 or IP65.
Can the energy case be customized?
B&W offers numerous customization options. You can have the energy case adapted to specific requirements - for example with additional connections or special configurations. This flexibility makes it particularly unique.
How safe is the transportation of B&W energy cases?
The energy cases are extremely safe. They are water-repellent, impact-resistant and protected against external influences. They are also designed to function reliably even in challenging situations such as heavy rain or extreme temperatures.
Who can I contact if I have technical queries about my energy case?
For further information and details, please do not hesitate to contact us. Please use the contact form for your inquiry.
